44
ED50/ED100/ED250 09-2021DL4617-003
dormakaba ED50/ED100/ED250 OHC Header
Setup and Troubleshooting Instructions
Chapter 18
 Install door signage, header cover
. Install door signage
.. Install door signage plated on type of door
installation.
Install applicable door signage as outlined in Chapter ,
ED/ED/ED door signage.
. Install header cover
.. Install header cover.
CAUTION
. Insure all wiring is secured inside of header.
. Check tightness of all wiring connections.
. Check ribbon cable connections.
Fig. 18.2.1 Single door header cover
1 1/4-20 x 1/2"
FHMS
1
Fig. 18.2.2 Header cover fastener
. Secure header cover to jamb brackets with
/- x /" flat head machine screws.
