Dormakaba ED50 - Page 43

43
ED50/ED100/ED250 09-2021DL4617-003
dormakaba ED50/ED100/ED250 OHC Header
Setup and Troubleshooting Instructions
Chapter 17
. Connect accessory wiring, single door
 Connect accessory wiring
.. Connect accessory wiring.
TIPS AND RECOMMENDATIONS
• Reference Chapter , Terminal
board connections, for
terminal board interfaces.
• Reference ED/ED
Sensor Installation and Wiring
Manual.
. Terminate all accessory wiring at
ED/ED/ED low voltage
terminal board in header.
. Secure all accessory wiring.
Fig. 17.1.1 Accessory wiring terminal board, ED100/ED250 operator on left example
. Connect accessory wiring, double doors
.. Connect accessory wiring.
TIPS AND RECOMMENDATIONS
• Reference Chapter , Terminal
Board Connections, for
terminal board interfaces.
• Reference ED/ED
Sensor Installation and Wiring
Manual.
. Terminate all accessory wiring for both
LH and RH doors at ED/ED/
ED low voltage terminal board
modules in header.
. Secure all accessory wiring in header.
.. Panic breakout switch wiring.
Reference Para. ...
.. Test system accessories.
Test functionality of all accessories.
.. Panic breakout switch wiring.
Reference OHC Installation Manual for
switch installation on inswing doors.
. Breakout switch wires terminate at X-
and a on ED/ED terminal board.
Remove jumper between  and a
(Fig. ..).
Fig. 17.2.1 Low voltage terminal board modules, double door
1 LH ED50/ED100/
ED250 controller
2 Low voltage
terminal board
module
3 RH ED50/ED100/
ED250 controller
1
2
2
3
1 Low voltage
terminal board
module
Fig. 17.1.2 Terminals 4 and 4a
4, 4a
Jumper
1
