ED50/ED100/ED250 09-2021DL4617-003
dormakaba ED50/ED100/ED250 OHC Header
Setup and Troubleshooting Instructions
Appendix A
Parameter
Value
range
Units
Factory
setting
Description
Release of hold-open system
0 - 1
. Upgrade care Fire Protection installed.
. Set parameter FC to . Users may release hold-open by manually moving door
in closed direction.
• A manual release button is not required.
• Hold-open release by manually moving door in closed direction is deactivated.
• A manual release button is required.
Castor angle for double doors
Primary door with astragal, angle active door must open before secondary door opens.
- °
Hinge clearance
• Clearance between hinges is critical for the calculated door angle.
• HS parameter may only have a small effect but the hinge clearance can be adjusted
in extreme cases to improve accuracy.
• Factory setting is * , mm, /".
• With CPD doors, setting must be changed to a negative value. A learning cycle is
then required as system creates an angle table as a function of the set parameters.
±
*
mm
*
±/
*
inches
Overhead concealed mode (OHC): Activation
of permanent open via night-bank input
0 - 1
Function disabled.
If night-bank signal is longer than seconds, operator changes to permanent open
mode.
Overhead concealed mode (OHC):
Adjustable behavior after blockage / hold
open
0 - 1
Standard behavior ( x restart).
Manual mode after blockage.
Reversing after trigger of approach side
safety sensor / opposite hinge side in
operating mode hd=
0 - 1
Standard behavior, stop.
Reversing
A.. Driving parameters detail.
