5.2 Setting the PARTIAL OPEN Function
The PARTIAL OPEN Function can be selected or set
by program switch or PDA. The PDA can also be used
to disable the parameterisation via program switch, so
that settings can only be made with the help of the
PDA.
The opening width of the door can be adjusted
individually. Starting from the full opening width, a
reduced opening width = partial opening width
may be set (e.g. in winter to reduce drafts.)
• Close the door.
• Set program switch to PERMANENT OPEN
• The door opens at low (creep) speed.
• As soon as the door reaches the desired partial opening
width, set the program switch to PARTIAL OPEN.
Programmschalter in Stellung TEILOFFEN schalten.
- The door stops and the control unit stores the desired
position.
- The door performs a closing cycle.
5.3. EMERGENCY OFF pushbutton (optional)
Only for ES 200 Easy and ES 200
ES 200 Easy / ES 200
The program switch is set to AUTOMATIC, PARTIAL OPEN or
EXIT ONLY.
• Push the EMERGENCY OFF pushbutton so that the motor
circuit is interrupted.
• The door comes to a halt and the leaves may be moved
manually.
EMERGENCY OPEN pushbutton (optional)
ES 200-2D
(See 3.FST.1 )
5.4. Night-/Bank Function (optional)
The program switch is set to OFF:
The door is accessible from the outside when the
system is activated by an external activator.
• The door unlocks and opens.
• The door closes again either immediately after the user has
passed the door or on expiry of the Night-/Bank hold-open
time.
• The door relocks.
5.5. Start-up following a power failure
After a power failure, the control unit performs a self-check of
approx. 5 sec. for safety reasons.
The door then closes at low (creep) speed and resumes the
preset program function.
5. Operating instructions
5.1. Program switch
The program switch to activate the door system is located near
the door system. During commissioning the EMERGENCY OFF
pushbutton, which is normally situated next to the program
switch, must be unlocked by turning the switch. The following
five functions can be selected at the program switch.
EXIT ONLY
OFF
AUTOMATIC
PARTIAL PENINGO
PERMANENT OPEN
MALFUNCTION-LED
only ES 200-2D
Program switch settings:
AUS The system cannot be used
automatically. In the case of units with
locking device, the door is locked
mechanically.
AUTOMATIC If a person or an object enters the
range of the detectors, the
door opens to its full opening width
and closes on expiry of the
preset hold-open time. The hold-open
time can be adjusted at the basic
module or with the aid of the PDA.
AUSGANG The external detector is deactivated;
the door is only accessible from the
inside (e.g. one-way function on close
of business). If a person or an object
enters the range of the internal
detector, the door opens to its full
opening width and closes on expiry of
the preset hold-open time.
TEILOFFEN If a person or an object enters the
range of the detectors, the door opens
to the preset partial open width and
closes on expiry of the hold-open time.
DAUERAUF The door opens at low (creep) speed to
its full opening width and remains in
this position until another function is
selected.
Störungs-LED The Malfunction LED indicates a fault,
which might constrain the escape route.
The door travels to its „open position“
and comes to a halt.
