Fault Possible causes Remedy
Door remains open in the program
switch settings: AUTOMATIC,
PERMANT OPENING, and
PARTIAL OPENING
Detector is emitting a continuous
signal
Remove connector of radar motion
detector. If fault is cured by this,
replace radar movement detector
Basic module indicates error ”1”
(obstruction during
commissioning)
The learning cycle has not been
performed (the door weight is still
undetermined)
Perform learning cycle
The blocking sensor is too sensitive
for the door set (e.g. small,
high and heavy door leaves)
Adjust blocking sensor to door set
with the help of the force
limitation (OPEN, CLOSE) and the
delay time via the PDA
Door does not open when the
program switch is set to:
AUTOMATIC, EXIT ONLY,
PERMANT OPEN, and
PARTIAL OPEN
External detector Remove activator connector and
bridge the input. If the fault is
cured by this, check supply
voltage (27 V) of the basic module
and the detectors. If it is okay
check and replace detectors if
required.
Internal detector Remove activator connector. If the
door opens, check supply voltage
(27 V) of the basic module and
the detectors. If it is okay check
whether self-monitoring detector
that works according to the failsafe
principle is connected.
Unpleasant operating noise Screw presses against track roller Replace or trim screw
Control unit displays error code “H” The basic module has been
connected to a 2D door system
and is expecting a FST module.
Restore original settings.
Perform a learning cycle.
ES 200 CO48:
The rubber belt doesn’t open the
door
ES 200 CO48:
Check the rubber belt,
replace if required.
DAC 300:
The solenoid doesn’t hold the
rubber belt.
DAC 300:
Check the solenoid and the
tension of the rubber belt,
replace if required.
