ES 200
8
DEEN
Disassembly, recycling and disposal
The disassemby of the door drive is carried out in the reverse
order of the installation instructions and is to be performed
by skilled personnel.
De-energize the door system before the disassembly.
Dispose of the product in an environmentally-
friendly manner.
Electronic parts and batteries may not be disposed
in the general trash.
Take them to a battery collection point for disposal
Always comply with the applicable national legal provisions.
Safety during mounting
• The working area has to be secured against unauthorised
access from other people. Falling items or tools might cause
injuries.
• The ES 200
Easy
has to be secured against water and other
liquids.
• In any case, the way of mounting and the mounting
equipment, like for example screws and wall plugs, have to
be adequate with regard to the structural conditions (steel
structure, wood, concrete etc.).
• The mounting of the ES 200
Easy
described herein is only
an example. Structural or local conditions, available tools or
other conditions might suggest a different approach.
• Following the successful installation of the system, the
settings and the proper function of the ES 200
Easy
and
the safety equipment have to be checked.
• Only specially qualified staff may open the power supply
housing.
• De-energise the ES 200
Easy
before removing the cover of
the power supply housing. Remove mains plug or switch off
fuse (with permanent power supply).
• Always pull at the plug and never at the cable when
unplugging the power supply.
Safety during commissioning
• The protective earth conductor has to be connected.
• The safety sensors are to be connected (see commissioning
instructions).
• The operator and the active panels are properly linked.
• The end stops are adjusted so that the sliding panels meet
the end stops when the system is adjusted to its maximum
opening width
• Furthermore the sealing profiles of the active panels and the
passive panels must not collide while the door is closed
• Separately supplied components such as the program
switch, the EMERGENCY OFF pushbutton and activators
(radar motion detectors, NIGHT-/BANK key switches) have
to be mounted and connected.
• Ensure that the door leaves run smoothly
• The rechargeable battery pack has been installed (optional).
Inspection and system approval
Before the first commissioning and depending on
requirements, however, at least once a year, the ES 200
Easy
has to be inspected by a properly qualified technician
and serviced if required. A person trained by DORMA has to
perform the inspection and approve the system with the aid of
the inspection book.
The respective results have to be documented in accordance
with DIN 18650-2 and the facility operator has to keep these
documents for at least one year.
We would recommend taking out a maintenance
agreement with DORMA.
Briefing:
Following the adjustment, commissioning and functional
testing of the door system, the operating instructions have to
be handed over to the facility operator and a briefing has to be
made.
Behaviour of door system during varying weather conditions
The safety sensors (infrared light curtains) are designed to
safeguard the passage area. When it comes to adjusting the
sensitivity of the sensors, the protection of people always has
top priority. From time to time, changing climatic conditions
(such as rain or snow), flying leaves or direct sunlight
(reflected by certain floor finishes) may accidentally trigger the
sensors. As soon as the light curtains have been triggered, the
door may remain open for up to one minute – as required by
a certain standard. This is only a standard procedure with the
only purpose to protect the users of the door system.
Maintenance
The system has to be de-energised (disconnected from power
supply) before performing any kind of maintenance work.
Remove the power plug or switch off the fuse (with permanent
power supply).
Care
The system has to be de-energised (disconnected from power
supply) before cleaning the system. Remove the power plug or
switch off the fuse (with permanent power supply).
You may clean the ES 200
Easy
with a damp cloth and
standard commercial detergents.
You should not use scouring agents for cleaning purposes as
they might damage the surface finish.
Ensure that no water or other liquids drop on or into the
ES 200
Easy
.
Never stick metal objects into the openings of the
ES 200
Easy
otherwise you might sustain an electric shock.
Wear
The following wear parts must be checked in regular intervals
and replaced if required in order to ensure the smooth
function of the unit.
• Track rollers: every 2 years
• Rubber end stops: at every service check
• Track rail: every 5 years
• Toothed belt: every 1,000,000 opening/closing cycle
• Floor guides: at every service check
• Brushes (optional)
• Battery pack ES200 complete, Order No. 04000160
Only use original spare parts.
