dormakaba Mounting instructions Operation
7.5.5 Unlocking time when using
an electrical door opener
(option)
If an electrical door opener is connected, this
is automatically detected.
1. Adjust the unlocking time.
2. Set the unlocking time with
potentiometer 4.
The unlocking time is infinitely adjustable
from approx. 0.2sec. – 3sec.
− = 0.2sec. unlocking time
+ = 3sec. unlocking time
7.5.6 End stop
Note
During commissioning, DIP
switch “A” has a different
function.
1. Switch DIP switch A to “OFF” position.
‣ The end stop is switched off.
→ The door is gently closed and held in the
“Door closed” position.
Suitable for smooth-running doors.
2. Switch DIP switch A to “ON” position.
‣ The end stop is switched on.
→ The door is accelerated in the last few
degrees before the “Door closed”
position.
The door is disengaged if it is closed.
Suitable for doors with high resistance.
