dormakaba Mounting instructions Operation
7.5 Settings
The following settings can be made by the
potentiometer (see 3.6):
• “PowerLess” operation mode
• Speed
• Hold-open time
• Opening angle or wall blanking
• Unlocking time
• End stop
• DIP switch
7.5.1 “PowerLess” operation mode
1. Switch power switch to “ON” position.
2. Switch program switch to position “I”
(“PowerMotion”).
3. Turn potentiometer 1 (speed) to the left
as far as possible to the “PowerLess”
position.
→ In “PowerLess” operation mode, the
door can be opened manually with
virtually zero
effort. The closing process takes place
automatically once the adjustable
hold-open time elapses.
7.5.2 Speed
1. Switch power switch to “ON” position.
2. Adjust the opening and closing time
(speed) with potentiometer 1.
• The default setting for the area of
movement from 0° - 90° is 10 sec.
• The default setting for the area of
movement from 90° - 0° is 10 sec.
• The speed is infinitely adjustable from 5
sec. to 10 sec. and applies for the area of
movement from an opening angle of 0° to
90°.
− = lowest speed
(10sec. travel time)
+ = highest speed
(5sec. travel time)
Note
Do not confuse the “PowerLess”
position with the lowest speed
position (directly in front of
“PowerLess”).
7.5.3 Hold-open time
1. Switch power switch to “ON” position.
2. Set the hold-open time with
potentiometer 2.
• The hold-open time is infinitely adjustable
from approx. 5sec. – 30sec.
− = 5sec. hold-open time
+ = 30sec. hold-open time
• In the “PowerLess” operation mode/
function, the hold-open time is adjustable
from approx. 0.5 sec. - 30 sec.
− = 0.5sec. hold-open time
+ = 30sec. hold-open time
7.5.4 Wall blanking
(only in connection with
optional sensors)
1. Switch power switch to “ON” position.
2. Adjust the wall blanking with
potentiometer 3.
The wall blanking is infinitely adjustable
from approx. 80-110°.
− = 80° opening angle
+ = 110° opening angle
