DRAIN AND CLEAN THE HYDRAULIC OIL TANK (CONTINUED)
Before filling the tank be sure the funnel is clean and 200 mesh (or finer) screen is used to strain the hydraulic oil.
13.Fill tank with recommended oil, checking the sight gauge as you fill. Refer to Hydraulic Oil Specifications .
14.Check the entire system to make sure all connections are tight and no leaks are found.
15.Start the truck’s engine and engage the pump.
WARNING
Moving equipment can be dangerous to bystanders. Serious injury or death can occur if a person is in the wrong area or is
not attentive to the operations. Clear the area of all unnecessary people before you operate the controls.
16.Operate the packing panel through 10 cycles to be sure all air is out of the circuits.
17.Operate the automated container lift mechanism.
18.Operate tailgate – full up and full down.
19.Operate body raise (dump units) – full up and full down.
20.With the packing panel in the retracted position and lift in the in-transit position, check tank oil level. If necessary, add
recommended as described under Check Oil Level .
