STANDARD TORQUE DATA FOR NUTS AND BOLTS
The following recommended torque data is for use as a general guideline. Recommended torque, in foot pounds, for all
Standard Application nuts and bolts provided in the following table.
NOTICE
Torque specifications on a drawing override torque values in the Standard Torque Data for Nuts and Bolts Table.
All thread surfaces are clean and lubricated with SAE-30 engine oil. See notice above.
Joints are rigid, that is no gaskets or compressible materials are used
When re-using nuts or bolts use minimum torque values
STANDARD TORQUE DATA FOR NUTS AND BOLTS TABLE
Bolt Size
(D)
Nut Type
(STD/Lock)
Thread
Turns per
Inch
(p)
Grade
Heil Plain Dry
Condition
Torque Value
(ft-lbs)
Heil Zinc
Plated
Fastener
Torque
Value
(ft-lbs)
Heil Lubricated
Fastener
Torque Value
(ft-lbs)
Heil Deformed
Lock Nut
Torque Value
(ft-lbs)
1/4
STD
20
5
9
8
6
0.25
8
13
12
8
28
5
10
9
7
8
15
13
10
Lock
20
5
6
8
8
28
5
7
8
10
5/16
STD
18
5
19
17
12
.3125
8
27
24
17
24
5
21
19
14
8
29
27
19
Lock
18
5
12
8
17
24
5
14
8
19
3/8
STD
16
5
33
30
22
.375
8
47
42
31
24
5
38
34
25
8
54
48
35
