SIDE ACCESS DOORS
Hinged access doors are located on each side of the unit. See the figure below.
WARNING
Make sure the unit is in the Lock-Out/Tag-Out mode when you do maintenance or service procedures, when you go in the
hopper, enter the side access doors, or climb on the body or equipment. Equipment can be operated when the unit is not in
the Lock-Out/Tag-Out mode. When the unit is not in the Lock-Out/Tag-Out mode, equipment operated while you do
maintenance or service procedures, enter the hopper or climb on the body or equipment can cause serious injury or death.
Figure 32. Side Access
Door
BODY SUMP DOORS
Sump doors are located on the front corner of each side of the body. Open the doors when cleaning out the sump area. A
cleaning tool is provided with each unit. Close the doors at all times except when cleaning. Cleaning should occur daily. See
the figure below.
Figure 33. Body Sump Doors
