INSIGHT™ STANDARD DIAGNOSTIC DISPLAY CABLE
See the figure below for a rear view of the display with cable connected.
Figure 53. Rear View of Display with Cable Connected
CORTEX CONTROLLER™ PROGRAMMING
Contact Heil Environmental for re-programming of the Cortex Controller.
PROGRAMMING CABLES AND ADAPTERS
Cortex Controller RS232 Cable
InSight™ CAN Programming Cable
USB to M12 Cable (USB to 7" and
12" Displays)
