14.10.6 Enclosure port immunity
Test
frequency
(MHz)
Band
1)
(MHz)
1) For some services, only the up-link frequencies are included.
Service
1)
Modulation
2)
2) The carrier shall be modulated using a 50% duty cycle square wave signal.
Maximum
power
(W)
Distance
(m)
Immunity
test level
(V/m)
385 380 to 390 TETRA 400 Pulse
modulation
2)
18 Hz
1.8 0.3 27
450 430 to 470 GMRS 4460,
FRS 460
FM
3)
± 5 kHz deviation
1kHz sine
3) As an alternative to FM modulation, 50% pulse modulation at 18 Hz may be used because, while it
does not represent actual modulation, it would be worst case.
20.328
710 704 to 787 LTE Band 13,
17
Pulse
modulation
2)
217 Hz
0.2 0.3 9
745
780
810 800 to 960 GSM 800/900,
TETRA 800,
iDEN 820,
CDMA 850,
LTE Band 5
Pulse
modulation
2)
18 Hz
20.328
870
930
1720 1700 to 1990 GSM 1800;
CDMA 1900;
GSM 1900;
DECT; LTE
Band 1, 3, 4,
25; UMTS
Pulse
modulation
2)
217 Hz
20.328
1845
1970
2450 2400 to 2570 Bluetooth,
WLAN, 802.11
b/g/n, RFID
2450, LTE
band 7
Pulse
modulation
2)
217 Hz
20.328
5240 5100 to 5800 WLAN 802.11
a/n
Pulse
modulation
2)
217 Hz
0.2 0.3 9
5500
5785
NOTE: If necessary to achieve the immunity test level, the distance between the transmitting antenna
and the ME equipment of ME system may be reduced to 1 m. The 1 m test distance is permitted by
IEC 61000-4-3.
