6 Use Instructions for NIOSH-approved full facepieces
What is what?
(see figure A1 and A2 on page 3)
Markings on the FPS 7000
The facepieces are differently marked:
1 Visor frame, top 2 Head harness
3 Sliding buckle 4 Neck support strap
5 Facepiece body 6 Flap
7 Cap 8 Visor frame, bottom
9 Nose cup valve 10 Nose cup
11 Visor 12 Connection piece
13 Button protector 14 Button
15 Speech diaphragm 16 Exhalation valve seat
17 Spring adapter with spring
and spring guide
18 Exhalation valve disk
19 Inhalation valve 20 Screw
21 Clip 22 O-ring
Connector P
Facepiece body EPDM
Size of facepiece
body
S (small), M (medium), L (large)
Size of nose cup 1 (small), 2 (medium), 3 (large)
Use
Prerequisites
In order to make sure that the correct facepiece size is used, perform
a quantitative fit test. The fit test is to be conducted in accordance
with the requirements outlined in the OSHA respiratory protection
standard 29 Code of Federal Regulations, Part 1910.134. A fit factor
of 500 is required. If the fit factor is not achieved, other appropriate
respiratory protection must be used.
Visor PC, F (fire brigade), EN 166
A (ballistic protection class/190 m/s)
T (ballistic protection at extreme tempera
tures,
tested at
-22 °F to +140 °F (
-30
°
C to +60
°
C)
with 190 m/s)
PCas (coated with scratch-resistant material)
Head harness CR, M/L or S
Hairnet H, M/L
9021721_5.book Seite 6 Donnerstag, 21. Mai 2015 11:44 11
