3.4 Approvals
A copy of the rating plate, the declaration of conformity
and the sensor data relevant for measurement
purposes are provided in the enclosed supplementary
documentation (part no. 90 33 655).
Explosion protection:
BVS 17 ATEX E 040 X certifies the intended use in
explosion-hazard areas and the measuring function for
explosion protection. PFG 19 G 001 X certifies the
measurement of oxygen deficiency and oxygen surplus
as well as the measuring function for toxic gases. See
the supplementary documentation for certified gases
and measured values (part no. 90 33 655).
CSA-specific information:
Only the combustible gas part of this instrument has
been tested for measuring accuracy.
Radio approval (X-am 8000 only):
The information for radio approval can be viewed in the
menu. For further information, see the following
chapter: "Opening information", page 46.
Approval-related accessories:
This chapter contains an overview of the key parts
covered by the BVS and PFG certification. Information
on other parts can be found in the spare parts list or can
be requested from Dräger Service. The same ambient
conditions that apply for the gas detector also apply for
the accessory. For further information see: "Gas
detection instrument", page 62.
The data logger is not part of the technical suitability
test.
3.5 Label
The energy supply label has a mark for a service label.
Here, a maximum of one service label and one year-
point label may be attached one on top of the other.
Further labels, conductive labels or labels with
conductive material or parts can have a negative effect
on inductive charging.
The rating plate on the gas detector must not be
concealed.
3.6 Sensor slots X-am 8000
4 Operation
4.1 Operating concept
Navigation is done with the 3 multifeature buttons and
the dynamic navigation bar (see Graphic E on the fold-
out page). The navigation bar changes dynamically
depending on the available interactions.
4.2 Symbol explanations
4.2.1 feature buttons
Description Part number
Carrying strap 8326823
Calibration adapter 8326821
Pump adapter with dust
and water filter
8326820
Induction charger 8325825
Term
Sensor slot
Configuration
HPP 1 (High Power Port) PID or IR sensor
HPP 2 (High Power Port) IR or CatEx sensor
EC 1-3 (Electro Chemical) EC sensors
Symbol Explanation
Confirm action/dialog / return to menu
Confirm all
Scroll up / through display
Scroll down / through display
Cancel action
Display quick menu
Display measuring channels individu-
ally
Display all measuring channels
Increase value
Decrease value
Repeat feature
Display menu
To Next Page
