Abbreviations and symbols
Abbreviations and symbols
Alarm
Air Mix
IPPV
Freq.
MV
No Air Mix
Paw
Paw y*
Paw t f
PEEP
Pv
¥
0
Rotary control for upper alarm limit
Paw -F
Mixing of 02 with ambient air,
approx. 60 % 02 by vol.
Intermittent Positive Pressure Ventilation
Ventilation frequency, strokes per minute
Minute volume, L/min.
No mixing with ambient air,
100 % 02 by volume
Airway pressure
Upper alarm limit of airway pressure
Lower alarm limit of airway pressure
Positive End Exspiratory Pressure
Supply pressure
Setting symbol for ventilation rate and
airway pressure during heart-lung
resuscitation
Audible alarm tone muting
