DRAMIŃSKI iScan mini – user guide
14
11. Cine loop current frame / all frames
12. Image refresh rate
13. Measurement result
14. Current settings
15. Battery charge level
16. Overall gain level
7.2. Button functions
Buttons have various functions, depending on the ultrasound scanner’s operation mode. Below are the default
uses of the buttons in scanning and freezing mode. Button functions may be modied using the Personalise
<8.1.> option
Imaging mode Frozen mode
1. ON/OFF, Freeze 1. ON/OFF, Unfreeze
2. Gain 2. Automatic follicle measurement
3. OK/Menu 3. Menu
4. Focus + 4. Save image
5. Focus - 5. Save cine
6. Depth - 6. Frame back
7. Depth + 7. Frame forward
