Vigor3200 Series User’s Guide
120
Click any Index number link to access into the following page for configuring load-balance
policy.
Each item is explained as follows:
Item Description
Enable
Check this box to enable this policy.
Protocol
Use the drop-down menu to choose a proper protocol for the
WAN interface.
Binding WAN interface
Choose the WAN interface (WAN1 / WAN2 / WAN3 /
WAN4 / WAN5) for binding.
Auto failover to other WAN – Check this button to lead the
data passing through other WAN automatically when the
selected WAN interface is failover.
Src IP Start
Type the source IP start for the specified WAN interface.
Src IP End
Type the source IP end for the specified WAN interface. If
this field is blank, it means that all the source IPs inside the
LAN will be passed through the WAN interface.
Dest IP Start
Type the destination IP start for the specified WAN interface.
Dest IP End
Type the destination IP end for the specified WAN interface.
If this field is blank, it means that all the destination IPs will
be passed through the WAN interface.
Dest Port Start
Type the destination port start for the destination IP.
Dest Port End
Type the destination port end for the destination IP. If this
field is blank, it means that all the destination ports will be
