Vigor3200 Series User’s Guide
309
Each item is explained as follows:
Item Description
Connection Status
If there is no USB storage disk connected to Vigor router, “No
Disk Connected” will be shown here.
Disk Capacity
Display the total capacity of the USB storage disk.
Free Capacity
Display the free space of the USB storage disk. Click Refresh
at any time to get new status for free capacity.
Index
Display the number of the client which connecting to FTP
server.
IP Address
Display the IP address of the user’s host which connecting to
the FTP server.
Username
Display the username that user uses to login to the FTP server.
When you insert USB diskette into the Vigor router, the system will start to find out such
device within several seconds.
4
4
.
.
1
1
4
4
.
.
5
5
S
S
y
y
s
s
l
l
o
o
g
g
E
E
x
x
p
p
l
l
o
o
r
r
e
e
r
r
Such page provides real-time syslog and displays the information on the screen.
F
F
o
o
r
r
W
W
e
e
b
b
S
S
y
y
s
s
l
l
o
o
g
g
Available parameters are explained as follows:
Item Description
Enable Web Syslog
Check this box to enable the function of Web Syslog.
Syslog Type
Use the drop down list to specify a type of Syslog to be
displayed.
Display Mode
There are two modes for you to choose.
