Vigor3200 Series User’s Guide
30
Item Description
interface.
WAN 1 Status ~ WAN 5
Status
Line
- Displays the physical connection of this interface.
Name
- Displays the name set in WAN1/WAN web page.
Mode
- Displays the type of WAN connection (e.g., PPPoE).
Up Time
- Displays the total uptime of the interface.
IP
- Displays the IP address of the WAN interface.
GW IP
- Displays the IP address of the default gateway.
TX Packets
- Displays the total transmitted packets at the WAN interface.
TX Rate
- Displays the speed of transmitted octets at the WAN
interface.
RX Packets
- Displays the total number of received packets at the WAN
interface.
RX Rate
- Displays the speed of received octets at the WAN interface.
Note: The words in green mean that the WAN connection of that interface is ready for
accessing Internet; the words in red mean that the WAN connection of that interface is not
ready for accessing Internet.
2
2
.
.
6
6
S
S
a
a
v
v
i
i
n
n
g
g
C
C
o
o
n
n
f
f
i
i
g
g
u
u
r
r
a
a
t
t
i
i
o
o
n
n
Each time you click OK on the web page for saving the configuration, you can find messages
showing the system interaction with you.
Ready indicates the system is ready for you to input settings.
Settings Saved means your settings are saved once you click Finish or OK button.
2
2
.
.
7
7
S
S
u
u
p
p
p
p
o
o
r
r
t
t
A
A
r
r
e
e
a
a
When you click the menu item under Support Area, you will be guided to visit
www.draytek.com and open the corresponding pages directly.
