Vigor3200 Series User’s Guide
140
Each item is explained as follows:
Item Description
Index
Display the number of the profile.
Service Name
Display the description of the specific network service.
Protocol
Display the transport layer protocol (TCP or UDP).
Public Port
Display the port number which will be redirected to the
specified Private IP and Port of the internal host.
Private IP
Display the IP address of the internal host providing the
service.
Status
Display if the profile is enabled (v) or not (x).
Press any number under Index to access into next page for configuring port redirection.
Available settings are explained as follows:
Item Description
Enable
Check this box to enable such port redirection setting.
Mode
Two options (Single and Range) are provided here for you to
choose. To set a range for the specific service, select Range. In
Range mode, if the public port (start port and end port) and the
starting IP of private IP had been entered, the system will
calculate and display the ending IP of private IP automatically.
Service Name
Enter the description of the specific network service.
Protocol
Select the transport layer protocol (TCP or UDP).
WAN Interface
Select the WAN interface used for port redirection.
Public Port
Specify which port can be redirected to the specified Private
IP and Port of the internal host. If you choose Range as the
port redirection mode, you will see two boxes on this field.
Simply type the required number on the first box. The second
one will be assigned automatically later.
