Vigor3200 Series User’s Guide
160
Item Description
Note: RT means routing domain for 2nd subnet.
Source/Destination IP
Click Edit to access into the following dialog to choose the
source/destination IP or IP ranges.
To set the IP address manually, please choose Any
Address/Single Address/Range Address/Subnet Address as
the Address Type and type them in this dialog. In addition, if
you want to use the IP range from defined groups or objects,
please choose Group and Objects as the Address Type.
From the IP Group drop down list, choose the one that you
want to apply. Or use the IP Object drop down list to choose
the object that you want.
Service Type
Click Edit to access into the following dialog to choose a
suitable service type.
To set the service type manually, please choose User defined
as the Service Type and type them in this dialog. In addition, if
you want to use the service type from defined groups or
objects, please choose Group and Objects as the Service
To Next Page
