Vigor3200 Series User’s Guide
258
Type (on Backup Profile field) - Display the connection type
for that profile, such as IPSec, PPTP, L2TP, L2TP over IPSec
(NICE), L2TP over IPSec(MUST) and so on.
Member2 (on Backup Profile field) - Display the dial-out
profile selected from the Member2 drop down list below.
Advanced – This button is available only when LAN to LAN
profile (or more) is created.
Detailed information for this dialog, see later section -
Advanced Load Balance and Backup.
Load Balance Profile
List
Set to Factory Default - Click to clear all VPN TRUNK-VPN
Load Balance mechanism profile.
No - The order of VPN TRUNK-VPN Load Balance
mechanism profile.
Status - “v” means such profile is enabled; ”x” means such
profile is disabled.
Name - Display the name of VPN TRUNK-VPN Load
Balance mechanism profile.
Member1 - Display the dial-out profile selected from the
Member1 drop down list below.
Active - “Yes” means normal condition. ”No” means the state
might be disabled or that profile currently is set with Dial-in
mode (for call direction) in LAN-to-LAN.
Type - Display the connection type for that profile, such as
IPSec, PPTP, L2TP, L2TP over IPSec (NICE), L2TP over
IPSec(MUST) and so on.
Member2 - Display the dial-out profile selected from the
Member2 drop down list below.
Advanced – This button is only available when there is one or
more profiles created in this page.
