Vigor3200 Series User’s Guide
262
A
A
d
d
v
v
a
a
n
n
c
c
e
e
d
d
L
L
o
o
a
a
d
d
B
B
a
a
l
l
a
a
n
n
c
c
e
e
a
a
n
n
d
d
B
B
a
a
c
c
k
k
u
u
p
p
After setting profiles for load balance, you can choose any one of them and click Advance for
more detailed configuration. The windows for advanced load balance and backup are different.
Refer to the following explanation:
Advanced Load Balance
Available settings are explained as follows:
Item Description
Profile Name
List the load balance profile name.
Load Balance Algorithm
Round Robin – Based on packet base, both tunnels will send
the packet alternatively. Such method can reach the balance of
packet transmission with fixed rate.
Weighted Round Robin –Such method can reach the balance
of packet transmission with flexible rate. It can be divided into
Auto Weighted and According to Speed Ratio. Auto Weighted
can detect the device speed (10Mbps/100Mbps) and switch
with fixed value ratio (3:7) for packet transmission. If the
transmission rate for packets on both sides of the tunnels is the
same, the value of Auto Weighted should be 5.5. According to
Speed Ratio allows user to adjust suitable rate manually.
There are 100 groups of rate ratio for Member1:Member2
(range from 1:99 to 99:1).
To Next Page
