Vigor3200 Series User’s Guide
334
Item Description
automatically.
Refresh
Click this link to refresh this page manually.
Index
Display the number of the data flow.
IP Address
Display the IP address of the monitored device.
TX rate (kbps)
Display the transmission speed of the monitored device.
RX rate (kbps)
Display the receiving speed of the monitored device.
Sessions
Display the session number that you specified in Limit Session
web page.
Action
Block - can prevent specified PC accessing into Internet
within 5 minutes.
Unblock – the device with the IP address will be blocked in
five minutes. The remaining time will be shown on the session
column.
Current /Peak/Speed
Current means current transmission rate and receiving rate
for WAN interface.
Peak means the highest peak value detected by the router in
data transmission.
Speed means line speed specified in WAN>>General Setup.
If you do not specify any rate at that page, here will display
Auto for instead.
