Vigor2920 Series User’s Guide
201
Refresh Seconds Use the drop down list to choose the time interval of refreshing data
flow that will be done by the system automatically.
Refresh Click this link to refresh this page manually.
Index Display the number of the data flow.
IP Address Display the IP address of the monitored device.
TX rate (kbps) Display the transmission speed of the monitored device.
RX rate (kbps) Display the receiving speed of the monitored device.
Sessions Display the session number that you specified in Limit Session web
page.
Action Block - can prevent specified PC accessing into Internet within 5
minutes.
Unblock – the device with the IP address will be blocked in five
minutes. The remaining time will be shown on the session column.
Current /Peak/Speed Current means current transmission rate and receiving rate for
WAN1/WAN.
Peak means the highest peak value detected by the router in data
transmission.
Speed means line speed specified in WAN>>General. If you do not
specify any rate at that page, here will display Auto for instead.
