Vigor2920 Series User’s Guide
200
Private IP:Port It indicates the source IP address and port of local PC.
#Pseudo Port It indicates the temporary port of the router used for NAT.
Peer IP:Port It indicates the destination IP address and port of remote host.
Interface It displays the representing number for different interface.
Refresh Click it to reload the page.
4
4
.
.
1
1
3
3
.
.
6
6
D
D
a
a
t
t
a
a
F
F
l
l
o
o
w
w
M
M
o
o
n
n
i
i
t
t
o
o
r
r
This page displays the running procedure for the IP address monitored and refreshes the data
in an interval of several seconds. The IP address listed here is configured in Bandwidth
Management. You have to enable IP bandwidth limit and IP session limit before invoke Data
Flow Monitor. If not, a notification dialog box will appear to remind you enabling it.
Click Diagnostics and click Data Flow Monitor to open the web page. You can click IP
Address, TX rate, RX rate or Session link for arranging the data display.
Enable Data Flow
Monitor
Check this box to enable this function.
