VigorAP 710 User’s Guide
2
1
1
.
.
2
2
L
L
E
E
D
D
I
I
n
n
d
d
i
i
c
c
a
a
t
t
o
o
r
r
s
s
a
a
n
n
d
d
C
C
o
o
n
n
n
n
e
e
c
c
t
t
o
o
r
r
s
s
Before you use the Vigor modem, please get acquainted with the LED indicators and
connectors first.
LED Status Explanation
Off The system is not ready or is failed. ACT
Blinking The system is ready and can work normally.
On The Repeater mode is on. Repeater
Blinking The Repeater mode is off.
On LAN is connected.
Off LAN is disconnected.
LAN
Blinking Data is transmitting (sending/receiving).
On The function of SSID is on. SSID1 – SSID4
Off The function of SSID is off.
On
(Green)
Press the button and release it within 2 seconds.
When the wireless function is ready, the green
LED will be on.
Off
Press the button and release it within 2 seconds to
turn off the WLAN function.
When the wireless function is not ready, the LED
will be off.
WLAN
ON/OFF/WPS
(Green LED)
Blinking
(Green)
Data is transmitting (sending/receiving).
WLAN
ON/OFF/WPS
(Orange LED)
Blinking
(
Orange
)
When WPS function is enabled by web user
interface, press this button for more than 2 seconds
to wait for client’s device making
network
connection through WPS.
When the orange LED blinks with 1 second cycle
for 2 minutes, it means that the AP is waiting for
wireless client to connect
with it.
