VigorAP 810 User’s Guide
34
Vigor router with Central AP Management function.
 Enable DHCP Client - When it is enabled, VigorAP
810
will be treated as a client and can be managed /
controlled
by AP Management server offered by Vigor
router (e.g.,
Vigor2860).
Enable Auto Provision – When it is enabled, VigorAP
810 will
be performed by zero-configuration, including
SSID, encryption
mode, channel, access control and etc.,
transmitted from the
Vigor router.
Specify an IP address
IP Address - Type in private IP address for connecting to a local
private network (Default: 192.168.1.2).
Subnet Mask - Type in an address code that determines the size
of the network. (Default: 255.255.255.0/ 24)
Default Gateway - In general, it is not really necessary to
specify a gateway for VigorAP 810. However, if it is required,
simply type an IP address as the gateway for VigorAP 810. It will
be convenient for the access point acquiring more service
(e.g.,
accessing NTP server) from Vigor router.
Enable Management VLAN - VigorAP 810 supports tag-based
VLAN for wireless clients accessing Vigor router. Only the
clients with the specified VLAN ID can access into VigorAP
810.
VLAN ID - Type the number as VLAN ID tagged on the
transmitted packet. “0” means no VALN tag.
DHCP Server
Configuration
DHCP stands for Dynamic Host Configuration Protocol. DHCP
server can automatically dispatch related IP settings to any local
user configured as a DHCP client.
Enable Server / Disable Server - Enable Server lets the modem
assign IP address to every host in the LAN.
Disable Server lets you manually or use other DHCP server to
assign IP address to every host in the LAN.
Relay Agent - Specify which subnet that DHCP server is located
the relay agent should redirect the DHCP request to.
Start IP Address - Enter a value of the IP address pool for the
DHCP server to start with when issuing IP addresses. If the 1st IP
address of your modem is 192.168.1.2, the starting IP address
must be 192.168.1.3 or greater, but smaller than 192.168.1.254.
End IP Address - Enter a value of the IP address pool for the
DHCP server to end with when issuing IP addresses.
Subnet Mask - Type in an address code that determines the size
of the network. (Default: 255.255.255.0/ 24)
Default Gateway - Enter a value of the gateway IP address for
the DHCP server.
Lease Time - It allows you to set the leased time for the
specified PC.
DHCP Server IP Address for Relay Agent - It is available
when Enable Relay Agent is selected. Set the IP address of the
