Drehmo D 30 - Types of Duty for Different Versions

Technical data
36
Standard version
Determine cable cross section on the basis of motor
data, cable length and the regional regulations!
Available cross sections:
Compact plug connector ∅150mm:
Signal cables: 0.5mm
2
– 2.5mm
2
Power: 0.5mm
2
– 2.5mm
2
Option: 0.5mm
2
– 6mm
2
or 1.5mm
2
– 16mm
2
Compact plug ∅100 mm:
Signal cables: 0.75mm
2
– 1.5mm
2
Power
1)
: 2.5mm
2
– 6mm
2
Explosion protection version
Terminal compartment in Ex e:
For available cable cross sections as well as pertain-
ing tightening torques, refer to table Approved con-
nection terminals [}37].
Contact rating
Thermal switch
max. 6.3A: 250VAC: 3,000 cycles
2.5A: 250VAC: cos φ = 1.0: 10,000 cycles
1.6A: 250VAC: cos φ = 0.6: 10,000 cycles
0.5A: 250VAC: cos φ = 0.6: 10,000 cycles
1.6A: 24VDC resistive: 10,000 cycles
1.25A: 48VDC resistive: 10,000 cycles
Fine silver contacts
400VAC: 2 A
250VAC: 7 A
250VDC: 0.5 A
Gold-plated contacts
Voltage: 5 – 30V
Current: 4 – 40 mA
The product of multiplied factors of current and
voltage may not exceed 0.2VA. For 1-phase AC, in-
terpret these values as peak values.
Electrical load
Refer to separate operation instructions BA_EM500x
or BA_EM700x
Motor temperature class refer to indications on name plate
Explosion protection
ATEX type examination certificate or IECEx Certific-
ate of Conformity. For respective marking, refer to
name plate.
Ambient temperature range Refer to indications on name plate in °C
Enclosure protection Refer to indications on name plate
Pollution degree
Within the actuator, pollution degree 1
(IEC60664-1). Outside the actuator, pollution de-
gree 2.
Vibration
The actuators are designed for a vibration range of
10 – 100Hz with 2g (high cross-over frequency ac-
cording to IEC60068-2-6).
1) 6mm
2
with small clamp washers
WARNING
Danger of explosion due to reduced heat dissipation for places of install-
ation >2000m above sea level.
Death or serious injury.
à When exceeding the value, please contact the manufacturer, since load and isola-
tion restrictions prevail for constant ambient temperature.
9.3
Types of duty for different versions
It is imperative to heed the types of duty even if the running times per valve cycle
(OPEN and CLOSED) exceed the limited operating times. The type of duty depends
upon the temperature range on the actuator name plate. Type of duty S2-xx min
(short-time duty) for multi-turn actuators and S4-xx % (periodic intermittent duty with
influence on starting procedure) for modulating actuators are to be considered.
With S2 duty rating, the maximum operating time of the actuator is indicated. Once
this time has expired, the actuator has to pause until it has cooled down to ambient
temperature +2Kelvin. In S4 type of duty, the on time value indicates the permitted
running time with reference to the switching cycle. A switching cycle is defined as time
between actuator start and next start (sum of actuator running time and pause time).
