Drehmo D 30 - Weights and Maximum Tripping Torques

Technical data
38
Manufacturer Designation Cross sections Dismantling
length
Torque
Phoenix USLKG 10N
1) 0.5 – 10mm
2
/0.5 – 10mm
2
2) 0.5 – 10mm
2
/0.5 – 6mm
2
10mm 1.5 – 1.8Nm
Phoenix UK 6 N
1) 0.2 – 10mm
2
2) 0.2 – 6mm
2
10mm 1.5 – 1.8Nm
Phoenix UK 10 N
1) 0.5 – 16mm
2
2) 0.5 – 10mm
2
/0.5 – 6mm
2
10mm 1.5 – 1.8Nm
1. solid wire/stranded
2. fine stranded/fine stranded with wire end sleeve
9.5
Weights and maximum tripping torques
In the table below, weights, speeds and maximum run torques of the actuators are in-
dicated.
Table10: Technical data
Actuator type Output speed/operating
speed
Maximum run torque Average weight in kg
D30Ex 5 – 160 15 23
DR30Ex 5 – 40 15 23
D59Ex 5 – 160 30 25
DR59Ex 5 – 40 30 25
D60Ex 5 – 160 30 29.5
DR60Ex 5 – 40 30 29.5
D120Ex 5 – 160 60 33.5
DR120Ex 5 – 40 60 33.5
D249Ex 5 – 80 125 33.5
D249
1)
120 100 33.5
D250Ex 5 – 50 125 69.5
D250Ex 80 – 160 125
2)
69.5
DR250Ex 5 – 40 125 69.5
D500Ex 5 – 80 250 80.5
D500Ex 120 250
2)
80.5
D500Ex 160 200
2)
80.5
DR500Ex 5 – 40 200 80.5
D1000Ex 5 – 50 500
2)
90.5
D1000Ex 80 400
2)
90.5
DR1000Ex 5 – 10 500 90.5
D2000Ex 40 – 80 1,000 220
D2000Ex
3)
160 300 220
DP(R)75Ex 8 – 34 33.5 38
DP(R)150Ex 8 – 34 75 38
DP(R)299Ex 8 – 34 150 38
DP(R)300Ex 8 – 34 150 40
DP(R)450Ex 8 – 34 225 40
DP(R)600Ex 8 – 67 300 46
DP(R)900Ex 8 – 67 450 46
DP1200Ex 7 – 75 600 51
DP(R)1200Ex 18 – 75 600 51
DP1800Ex 7 – 75 900 51
DP(R)1800Ex 18 – 75 900 51
1) 200Nm maximum tripping torque.
2) For these devices, the gearing heats up more than the motor. The heating up is not detected by the
actuator. It is therefore imperative to heed the maximum run torque and the type of duty.
3) For this version, the maximum tripping torque is restricted to 1000Nm.
