Identification
7
2
Identification
The following section describes the characteristics allowing identification of the re-
spective DREHMO actuator.
2.1
Name plates
Each actuator is equipped with an actuator and a motor name plate including informa-
tion required for unambiguous identification. For commissioning, service and mainten-
ance, additional actuator-relevant data is indicated on the name plates.
Figure1: Actuator name plate for Ex
DREHMO
Zum Eichstruck 10
D-57482 Wenden
Made in
Germany
serial-no.
Geräte-Nr.
Antriebs-Typ
actuator-type
Zündschutzart
prot. class
torque-range
Md-Bereich
speed
Drehzahl
ambient temperature
Umgebungstemperatur
enclosure
Schutzart
Nm
IP
min
-1
Nm
operating time
Stellzeit
modulating torque
max. Regelmoment
s/
°C...+– °C
179074
Figure2: Actuator name plate for non explosion-proof
DREHMO
Zum Eichstruck 10
D-57482 Wenden
Made in Germany
serial-no.
Geräte-Nr.
Antriebs-Typ
actuator-type
torque-range
Md-Bereich
speed
Drehzahl
ambient temperature
Umgebungstemperatur
enclosure
Schutzart
Nm
IP
min
-1
Nm
operating time
Stellzeit
modulating torque
max. Regelmoment
s/
°C...+– °C
127055
Figure3: Motor name plate
cos
φ
Motor-Nr.
A
Hz
V
KW
Motor-No.
Motor-Typ
Motor-Type
Schutz
Protection IEC 60034-1
I.Cl.
min
DREHMO
Topfmotor
124248
-
The actuator name plate is selected according to the actuator version and fixed to the
actuator.
Please always state the device number for any product inquiries. The product can be
unambiguously identified using this number and the technical data as well as order-re-
lated data pertaining to the device can be requested.
2.2
Actuator designation
The following example is used to explain the actuator designation:
