Dremel 3D20 Idea Builder User Manual

4
General Safety Warnings .............................................................2
Symbols .......................................................................................5
FCC Compliance..........................................................................6
Information on Intellectual Property .............................................6
Specifications ...............................................................................7
3D20 Resources ..........................................................................8
Glossary of Terms ........................................................................8
Getting To Know Your Dremel 3D20 ..........................................10
Introduction ................................................................................12
Kit Contents and Unpacking.......................................................12
Touch Screen .............................................................................14
Software Install and Registration ...............................................21
Dremel Software Overview ........................................................22
Getting Ready to Build ...............................................................25
Building ......................................................................................28
Building From The SD Card .......................................................29
Building From Your Computer....................................................30
Removing Your Object ...............................................................31
Unloading and Replacing Filament Spool ..................................32
Maintenance and Service...........................................................32
Best Practices ............................................................................35
Dremel® Consumer Limited Warranty .......................................36
Table of Contents
This product may contain or discharge chemicals known to the State of
California to cause cancer and birth defects or other reproductive harm.
!
WARNING
Additional Safety Warnings
DM 2610035691 07-14_3D20 7/3/14 2:41 PM Page 4

Dremel 3D20 Idea Builder Specifications

General

Printing material	Polylactic acid (PLA)
Layer thickness (min)	0.1 mm
Number of print heads	1
Maximum build size (WxDxH)	228 x 149 x 139 mm
Control type	Touch
Product color	Blue, Grey, White
Viewing window	Yes
Display diagonal	3.5 \
Display technology	IPS
Maximum extruder tip temperature	230 °C
3D scanner	No
Compatible memory cards	SD
AC input voltage	230 V
Cables included	USB
Number of print platform stickers	2

Weight and Dimensions

Depth	335 mm
Width	485 mm
Height	400 mm
Weight	8850 g
