Dremel 3D20 Idea Builder User Manual

14
Touch Screen
Using your Dremel 3D20 without a computer is easy with the onboard software and full color
touch screen.
Before building your model we want to familiarize you with the touch screen menu structure
and options.
Observe all provided warnings and safety instructions when using the
Dremel 3D20. Failure to do so may result in fire, equipment damage,
property damage or personal injury.
!
WARNING
BUILD
Select a model file from your Dremel 3D20’s
onboard memory by tapping the Dremel 3D20 icon
or select a model file from SD card by tapping the
SD card icon.
After a model is selected, a pop-up window will
appear on the touch screen with the following
options:
DM 2610035691 07-14_3D20 7/3/14 2:41 PM Page 14

Dremel 3D20 Idea Builder Specifications

General

Printing material	Polylactic acid (PLA)
Layer thickness (min)	0.1 mm
Number of print heads	1
Maximum build size (WxDxH)	228 x 149 x 139 mm
Control type	Touch
Product color	Blue, Grey, White
Viewing window	Yes
Display diagonal	3.5 \
Display technology	IPS
Maximum extruder tip temperature	230 °C
3D scanner	No
Compatible memory cards	SD
AC input voltage	230 V
Cables included	USB
Number of print platform stickers	2

Weight and Dimensions

Depth	335 mm
Width	485 mm
Height	400 mm
Weight	8850 g
