Dremel 3D20 Idea Builder User Manual

7
Functional Description and Specifications
BUILDING
Extruder: Single extrusion
Extruder temperature: Up to 230°C (397°F)
Operating Interface: 3.5” full color IPS touch
screen
Maximum Build Volume: 9” x 5.9” x 5.5”
(230mm x 150mm x 140mm)
Layer Thickness: 4 mil | 0.004 inches 100
microns | 0.10 mm
Filament Colors: See Dremel3D.com for
color choices
SD Card: Up to 32GB in size (3D20 will not
work with SD cards larger than 32GB)
Internal Storage: 4GB
WEIGHT & DIMENSIONS
Weight (without spool): 8.8kg (19lbs 8oz)
Dimensions: 19.1” x 15.7” x 13.2” (485mm x
400mm x 335mm)
FILAMENT
ONLY works with Dremel PLA filament
Filament: 1.75mm PLA
(Biodegradable/Renewable)
FILAMENT STORAGE
All polymers degrade with time. Do not
unpack until filament is needed. Filament
should be stored at room temperature: 16-
29° C (60-85° F)
SOFTWARE
Dremel 3D20 comes with complimentary
Dremel 3D software for Windows and Mac
OSX. This application converts your 3D
digital files into buildable files.
MINIMUM HARDWARE REQUIREMENTS
A PC with these minimum requirements will
be required to run the Dremel® 3D Software
Processor: Multi-core processor - 2 GHz or
faster per core
System RAM: 2 GB
Screen Resolution: 1024x768
USB port
WINDOWS REQUIREMENTS
Dremel® Software runs on 32 and 64-bit
Operating Systems
Windows Vista or later
MAC OSX REQUIREMENTS
Dremel® Software runs on Mac OSX 10.8 or
later
ELECTRICAL REQUIREMENTS
3D20 input rating: 120V, 60Hz, 1.2A
OPERATING ENVIRONMENT
Room Temperature: 16-29° C (60 - 85° F)
Level workspace
Dry workspace environment
15.7” (400mm)
19.1” (485mm) 13.2” (335mm)
WALL
8” (203mm)
8” (203mm)8” (203mm)
14” (356mm)
DM 2610035691 07-14_3D20 7/3/14 2:41 PM Page 7

Dremel 3D20 Idea Builder Specifications

General

Printing material	Polylactic acid (PLA)
Layer thickness (min)	0.1 mm
Number of print heads	1
Maximum build size (WxDxH)	228 x 149 x 139 mm
Control type	Touch
Product color	Blue, Grey, White
Viewing window	Yes
Display diagonal	3.5 \
Display technology	IPS
Maximum extruder tip temperature	230 °C
3D scanner	No
Compatible memory cards	SD
AC input voltage	230 V
Cables included	USB
Number of print platform stickers	2

Weight and Dimensions

Depth	335 mm
Width	485 mm
Height	400 mm
Weight	8850 g
