Dremel 3D20 Idea Builder User Manual

8
Glossary of Terms
3D20 Resources
Resource Description Location
Quick Start Guide Provides illustrated walkthrough
of how to un-box your 3D20 and
start building out of the box.
Printed version of the Quick Start
Guide is located in the rectangular
component carton. It is also
available on www.dremel3d.com
3D20 Website Provides the latest 3D20
software, product information,
and customer support.
www.dremel3d.com
3D20 Customer
Support
Contact Dremel for product
support, maintenance, and
service.
1-844-4DRML3D
(1-844-437-6533)
www.dremel3d.com
Dremel 3D20
Software
Allows you to upload, edit, and
build 3D files. You can also
change device settings and
order supplies.
Installed from www.dremel3d.com
or from SD card provided with the
Dremel 3D20.
Term Definition
Build Platform The flat surface used by your Dremel 3D20 to build objects.
Build Platform Clip Clip located at the front of the build platform base that is used to secure the build
platform in place.
Build Tape Adhesive tape similar to blue painter’s tape that improves the consistency of your
objects and helps them stick to the build plate surface.
Build Volume The three dimensional (3D) amount of space that an object will use once it is
completed. Your Dremel 3D20 has a maximum build volume which means that
objects with a larger build volume cannot be built unless they are resized or broken
into sub-objects.
Door Your Dremel 3D20 has a door located on the front panel. This allows for easy access
to the build platform, extruder, filament, and your objects. This door is made with a
transparent material so you can monitor the progress of your objects while keeping
the build environment stable.
Lid Your Dremel 3D20 has a removable lid on the top. This allows for more access to the
build platform, extruder, filament, and objects when necessary.
Limit Switch Switch that is activated by the motion of the extruder or build platform when the end
of travel is reached.
Extruder An assembly that uses gears to pull filament through the extruder intake, heat the
filament to the build temperature, and push the heated filament out of the extruder tip.
Extruder Fan A fan used to cool the outer assembly of the extruder and gear motor.
DM 2610035691 07-14_3D20 7/3/14 2:41 PM Page 8

Dremel 3D20 Idea Builder Specifications

General

Printing material	Polylactic acid (PLA)
Layer thickness (min)	0.1 mm
Number of print heads	1
Maximum build size (WxDxH)	228 x 149 x 139 mm
Control type	Touch
Product color	Blue, Grey, White
Viewing window	Yes
Display diagonal	3.5 \
Display technology	IPS
Maximum extruder tip temperature	230 °C
3D scanner	No
Compatible memory cards	SD
AC input voltage	230 V
Cables included	USB
Number of print platform stickers	2

Weight and Dimensions

Depth	335 mm
Width	485 mm
Height	400 mm
Weight	8850 g
