DRIFT Stealth 2 User Manual

6
The Drift Stealth 2 has an easy-to-use menu system which can be navigated using
the camera’s three control buttons.
Mode Selection
The Mode Selection menu is used to select the camera mode.
On pressing the MODE button, the camera will switch between the 4 recording
modes and the Camera Settings. The LCD screen backlight will take over the
colour for the selected mode and the camera is ready to capture.
For more information about the four camera modes, (see p7-12).
Cycle Options
The CYCLE button is used to select specific settings for each of the four camera
modes, as well as cycle through setting options.
To change the settings of the current camera mode press the CYCLE button. This
will change the settings between a selection of presets.
For more information about the four camera modes and their settings, (see p7-12).
Camera Settings Menu
The Camera Settings menu is used to view and adjust camera settings.
For full details, (see p13).
Camera Menu System
MODE/Simultaneous Photo/Video
Tag Button
CYCLE OPTION Button
ACTION Button (On/O/Rec/Stop)
LED Indicator
Current Mode
25 FPS
1080p
12:05:59
10s
5MP
129
Settings mode - Screen reference
EXPOSURE
-2.0, -1.0, 0, +1.0, +2.0
SELF-TIMER
OFF, 3S, 5S, 10S
VIDEO FORMAT
MP4 / MOV
VIDEO TAGGING
ON / OFF
VIDEO TAGGING INTERVAL
10s, 30s, 1MIN, 2MIN, 5MIN
VIDEO STANDARD
NTSC (30) / PAL (25)
WI-FI
OFF / ON
OFF / ON
MIC SENSITIVITY
OFF / LOW / MED / HIGH
LCD BACKLIGHT
ON / OFF
LCD BACKLIGHT TIMER
OFF / 5S / 10S / 20S / 1MIN
REMOTE CONTROL
YES / NO
REMOTE PAIRING
ONE TO ONE / ONE TO ALL
REMOTE LED
ON / OFF
CAMERA LED
ON / OFF
CAMERA OFF
OFF / 2MIN / 5MIN
DATE
YEAR / MONTH / DAY
DATE / TIME STAMP
ON / OFF
LANGUAGE
ENGLISH / FRANCAIS / DEUTSCH
ESPANOL / ITALIANO / PORTUGUES
JAPANESE / RUSSIAN / DU
TCH
DANISH / POLISH / ROMANIAN
SWEDISH / CZECH / GREEK
FINNISH
RESET SETTINGS
YES / NO
FORMAT MEMORY CARD
YES / NO
FIRMWARE VERSION
CURRENT VERSION
Red boxes indicate
Default Settings
CLONE MODE
1st screen of
Settings Mode.
2nd screen of
Settings Mode.
When a setting is
highlighted, the text
scrolls from left to right
to show the whole
description (as shown
in the images below).
As user scrolls through
settings, the selected
setting is highlighted.
GNITTE
SS
Exposur
e
Self
Timer
Video Format
M
P4
X Video Tag.
Video Stand
Clone Mode
WI-FI
NTSC
X
X
0
GNITTESS
Exposure
Self Timer
Video Format
M
P4
X
0
GNITTESS
Exposure
Self Timer
Video Format M
P4
X
0
X
Video Tag.
Video Standa
Clone Mode
WI-FI
NTSC
X
X
X
Video Tag.
ideo Standar
Clone Mode
WI-FI
NTSC
X
X
X Video Tag.
deo Standard
Clone Mode
WI-FI
NTSC
X
X
X Video Tag.
eo Standard
Clone Mode
WI-FI
NTSC
X
X
X Video Tag.
o Standard
Clone Mode
WI-FI
NTSC
X
X
X
14/03/2013
19
Figure 8: Stealth 2 Top View
C
2-20
5MP
Resolution
5MP
...
3s
1s - 3/s
SETTINGS
Wi-Fi
Figure 10:
Mode Selection Flow Chart
Figure 9: Preview Screen
Recording Mode
Exposure
Battery SD Card
25 FPS
1080p
12:05:59
X
0.0
87%
87%
87%
87%
87%
87%
87%
87%
87%
87%
EXP -2.0
EXP -2.0
EXP -2.0
EXP -2.0
EXP -2.0

DRIFT Stealth 2 Specifications

General

Video resolutions	848 x 480, 1280 x 720, 1280 x 960, 1920 x 1080 pixels
Maximum frame rate	120 fps
Supported video modes	1080p, 720p, 960p
Video formats supported	H.264, MP4
Maximum video resolution	1920 x 1080 pixels
Photo mode	Yes
Sensor type	CMOS
Total megapixels	12 MP
Optical sensor size	1/3 \
Effective megapixels (movie)	3 MP
Light exposure modes	Auto, Manual
Display diagonal	1.3 \
Field of view (FOV) angle	135 °
USB connector type	Micro-USB B
USB 2.0 ports quantity	1
Storage media	Internal memory + Memory card
Internal memory	0.256 GB
Compatible memory cards	MicroSD (TransFlash), SDHC, SDXC
Maximum memory card size	32 GB
GPS (satellite)	No
Product color	Black
Protection features	Dust resistant
Cables included	Micro-USB
Mac operating systems supported	Mac OS X 10.2 Jaguar, Mac OS X 10.3 Panther, Mac OS X 10.4 Tiger, Mac OS X 10.5 Leopard, Mac OS X 10.6 Snow Leopard, Mac OS X 10.7 Lion, Mac OS X 10.8 Mountain Lion, Mac OS X 10.9 Mavericks
Windows operating systems supported	Windows XP Home
Battery voltage	3.7 V
Battery capacity	1500 mAh
Battery life (max)	3 h

Weight and Dimensions

Depth	80 mm
Width	42.6 mm
Height	27.4 mm
Weight	97 g
