Tamarisk
®
Camera Control Software User Guide
1.3 LENS CALIBRATION REQUIREMENTS
The following hardware is needed to calibrate the camera successfully:
1. Pass Key to enable the Lens Calibration tab
2. A Tamarisk
®
with lens focused at infinity running:
a. FPGA RTL ver: V01.00.0080 or newer
b. CPU SW ver: X1.P1.01.13.13 or newer -OR- X1.Px.00.xx.xx
3. A USB cable or RS232 cable and power
4. One or two thermally stable black bodies. Ideally, the calibration process uses a
controllable black body, but any thermally stable and uniform body is acceptable. The
black body must completely fill the field of view with a uniform scene. DRS recommends
the following black body manufactures and models:
a. Santa Barbara Infrared, Inc.
www.sbir.com
Model: Infinity black body and controller
b. CI Systems
www.ci-systems.com
Model: sR-800
