DRS Technologies Tamarisk 640

Other manuals for DRS Technologies Tamarisk 640

User Manual44 pages

Software Interface Control Document81 pages

Questions and Answers

B
Benjamin RichAug 8, 2025
What to do if my DRS Technologies Tamarisk 640 Security Camera shows 'NO ATTACHED DEVICES FOUND'?
- N
  Nicholas CameronAug 9, 2025
  If your DRS Technologies Security Camera displays 'NO ATTACHED DEVICES FOUND', ensure the camera interface cable is correctly inserted into the 30-pin electrical interface on the camera and the break out box. If using USB, verify the mini-USB to USB cable is properly connected to the break out box and PC. For RS232 setups, confirm the external DC power supply is connected to the camera’s break out box and is turned on. Check that the communication cable (USB) is not damaged. Finally, if using a DC power supply, verify it's on, supplying the correct voltage, and providing enough current.
D
darlene60Aug 15, 2025
How to fix poor video quality on a custom lens calibrated DRS Technologies Tamarisk 640?
- M
  Maurice KennedyAug 15, 2025
  If your custom lens calibrated DRS Technologies Security Camera has poor video quality, focus on a distant object instead of a uniform black body. Make sure the uniform black body is stable before calibrating the custom lens. Verify the custom lens calibration option is enabled by selecting the correct calibration table. Power cycle the camera to apply calibration settings. Adjust the temperature of the black bodies to ensure adequate dynamic range. Ensure no air is blowing on the camera or black body during calibration. Confirm the custom lens and mount are tightly coupled to the TIM. Do not rely on the analog video output to assess video quality.
B
Brenda Leon MDAug 23, 2025
Why are the Custom Lens Calibration and Custom Pixel Map tabs non-functional on my DRS Technologies Tamarisk 640?
- K
  Kimberly WilliamsAug 23, 2025
  The Custom Lens Calibration and Custom Pixel Map tabs are only enabled for DRS Technologies Security Cameras that have FPGA firmware version 01.00.0076 or higher.
B
brian40Oct 31, 2025
Why is there no video or poor video from my DRS Technologies Security Camera?
- D
  Denise AdamsOct 31, 2025
  If you're experiencing no video or poor video quality from your DRS Technologies Security Camera, first, check that a video cable is securely connected between the camera and the video display device. Ensure both the camera and the display device are powered on and working. Try using a different video source to rule out issues with the cable or display. Also, confirm the bits per pixel setting and ensure your frame grabber or video display is configured correctly to avoid strange video effects. If you're using a USB port frame grabber, make sure it's a USB 2.0 (or greater) port. The frame grabber device driver must be installed. Also, ensure that the camera's shutter is open and the lens isn't blocked. Verify that your video display device supports the camera's output, and that the camera ...

Summary

Safety Instructions

Notifications: CAUTION, WARNING, and NOTE

Explains the different types of notifications used to alert users to risks and provide guidance.

Hardware Setup and Configuration

Hardware Configuration Options

Presents three different configurations for viewing camera output video, detailing required hardware for each setup.

Software Installation Guide

Launching the Software Installer

Installing the Camera Control Software

Guides the user through the steps of installing the Camera Control Software, including license agreements and setup types.

Getting Started with Setup and Operation

Starting the Camera Control Software

Camera Control Software Features

Settings Tab Configuration

Allows configuration of camera settings through task panes like Calibration, Image Orientation, Polarity, Shutter, Symbology, and Password.

Video Tab Settings

AGC Tab Controls

Pan and Zoom Tab Functionality

Lens Calibration Process

Explains the theory and process for custom lens calibration, including setup, data storage, and upload/download procedures.

Pixel Map Utility

Utilities Tab Functions

Uninstalling the Software

Removing Software via Install Utility

Uninstalling via Start Menu Prompt

Uninstalling via Control Panel

Troubleshooting Common Issues

No Attached Devices Found

Provides solutions for when the software fails to detect a connected camera, covering connection and driver issues.

No or Poor Video from Camera

Offers troubleshooting steps for missing or low-quality video display from the camera.

Calibration and Pixel Map Tabs Non-functional

Poor Video with Custom Lens Calibration
