DSC HS2016 Reference Manual

Section 6: Programming Worksheets
[009] [001] - [164] PGM Types
116 – Away Armed Status 148 – Ground Start 203 – Follower-Zones 17-24 216 – Follower-Zones 120-128
117 – Stay Armed Status 149 – Alt. Communicator 204 – Follower-Zones 25-32
120 – Away Armed/no Bypass
Status
155 – System Trouble 205 – Follower-Zones 33-40
121 – Command Output 1 156 – Latched System Event 206 – Follower-Zones 41-48
(3-Digit Decimal)
Valid Range: 001-216
001 Default: 121 Command Output 1
002 Default: 156 System Event
003 - 164 Default: 101 Burg and Fire Bell Follower
Description on page 72
001 – PGM 1: 002 – PGM 2: 003 – PGM 3: 004 – PGM 4:
005 – PGM 5: 006 – PGM 6: 007 – PGM 7: 008 – PGM 8:
009 – PGM 9: 010 – PGM 10: 011 – PGM 11: 012 – PGM 12:
013 – PGM 13: 014 – PGM 14: 015 – PGM 15: 016 – PGM 16:
017 – PGM 17: 018 – PGM 18: 019 – PGM 19: 020 – PGM 20:
021 – PGM 21: 022 – PGM 22: 023 – PGM 23: 024 – PGM 24:
025 – PGM 25: 026 – PGM 26: 027 – PGM 27: 028 – PGM 28:
029 – PGM 29: 030 – PGM 30: 031 – PGM 31: 032 – PGM 32:
033 – PGM 33: 034 – PGM 34: 035 – PGM 35: 036 – PGM 36:
037 – PGM 37: 038 – PGM 38: 039 – PGM 39: 040 – PGM 40:
041 – PGM 41: 042 – PGM 42: 043 – PGM 43: 044 – PGM 44:
045 – PGM 45: 046 – PGM 46: 047 – PGM 47: 048 – PGM 48:
049 – PGM 49: 050 – PGM 50: 051 – PGM 51: 052 – PGM 52:
053 – PGM 53: 054 – PGM 54: 055 – PGM 55: 056 – PGM 56:
057 – PGM 57: 058 – PGM 58: 059 – PGM 59: 060 – PGM 60:
061 – PGM 61: 062 – PGM 62: 063 – PGM 63: 064 – PGM 64:
065 – PGM 65: 066 – PGM 66: 067 – PGM 67: 068 – PGM 68:
069 – PGM 69: 070 – PGM 70: 071 – PGM 71: 072 – PGM 72:
073 – PGM 73: 074 – PGM 74: 075 – PGM 75: 076 – PGM 76:
077 – PGM 77: 078 – PGM 78: 079 – PGM 79: 080 – PGM 80:
081 – PGM 81: 082 – PGM 82: 083 – PGM 83: 084 – PGM 84:
085 – PGM 85: 086 – PGM 86: 087 – PGM 87: 088 – PGM 88:
089 – PGM 89: 090 – PGM 90: 091 – PGM 91: 092 – PGM 92:
093 – PGM 93: 094 – PGM 94: 095 – PGM 95: 096 – PGM 96:
097 – PGM 97: 098 – PGM 98: 099 – PGM 99: 100 – PGM 100:
101 – PGM 101: 102 – PGM 102: 103 – PGM 103: 104 – PGM 104:
105 – PGM 105: 106 – PGM 106: 107 – PGM 107: 108 – PGM 108:
109 – PGM 109: 110 – PGM 110: 111 – PGM 111: 112 – PGM 112:
113 – PGM 113: 114 – PGM 114: 115 – PGM 115: 116 – PGM 116:
117 – PGM 117: 118 – PGM 118: 119 – PGM 119: 120 – PGM 120:
121 – PGM 121: 122 – PGM 122: 123 – PGM 123: 124 – PGM 124:
- 133 -

DSC HS2016 Specifications

General

Mounting Type	Wall mount
Power Supply	16.5VAC
Battery Backup	12VDC
Operating Temperature	32°F to 120°F (0°C to 49°C)
Dimensions	267mm
