Section 6: Programming Worksheets
[009] [001] - [164] PGM Types
125 – PGM 125: 126 – PGM 126: 127 – PGM 127: 128 – PGM 128:
129 – PGM 129: 130 – PGM 130: 131 – PGM 131: 132 – PGM 132:
133 – PGM 133: 134 – PGM 134: 135 – PGM 135: 136 – PGM 136:
137 – PGM 137: 138 – PGM 138: 139 – PGM 139: 140 – PGM 140:
141 – PGM 141: 142 – PGM 142: 143 – PGM 143: 144 – PGM 144:
145 – PGM 145: 146 – PGM 146: 147 – PGM 147: 148 – PGM 148:
149 – PGM 149: 150 – PGM 150: 151 – PGM 151: 152 – PGM 152:
153 – PGM 153: 154 – PGM 154: 155 – PGM 155: 156 – PGM 156:
157 – PGM 157: 158 – PGM 158: 159 – PGM 159: 160 – PGM 160:
161 – PGM 161: 162 – PGM 162: 163 – PGM 163: 164 – PGM 164:
[010] [000 - 164] PGM Attributes
[000] – Main Bell
Mask
Description on page 77
R 01 – Fire Alarm
R 02 – CO Alarm
R 03 – Burglary Alarm
R 04 – Flood Alarm
R 05 – Bell Squawks
001-164 PGM Attributes
PGM 1-164:
100 – Null PGM
101 – Fire and Burglary R 01 – True Output
102 – Delay Fire and Burg R 01 – True Output
103 – Sensor Reset [*][7][2] o 03 – Code Required
109 – Courtesy Pulse R 01 – True Output
111 – Keypad Buzzer Follow
R 01 – True Output
o 02 – Timed Output
R 09 – Entry Delay
R 10 – Exit Delay
R 11 – Door Chime
R 12 – Keypad Buzzer Zone
R 13 – Audible Exit Zone
R 14 – Auto-Arm Pre-Alert
114 – Ready To Arm R 01 – True Output
115 – Armed Status R 01 – True Output
116 – Armed Away Mode R 01 – True Output
117 – Armed Stay Mode R 01 – True Output
120 – Away Armed No Bypass R 01 – True Output
121 – Command Output 1
R 01 – True Output
o 02 – Timed Output
R 03 – Code Required
R Schedule 001
122 – Command Output 2
R 01 – True Output
o 02 – Timed Output
o 03 – Code Required
R Schedule 001
