DSC HS2016 Reference Manual

Section 6: Programming Worksheets
[010] [000 - 164] PGM Attributes
123 – Command Output 3
R 01 – True Output
o 02 – Timed Output
o 03 – Code Required
R Schedule 001
124 – Command Output 4
R 01 – True Output
o 02 – Timed Output
o 03 – Code Required
R Schedule 001
129 – Partition Status Alarm
Memory
R 01 – True Output
132 – Holdup Output
R 01 – True Output
o 02 – Timed Output
133 - Burglary Verified R 01 – True Output
146 – TLM And Alarm R 01 – True Output
147 – Kissoff Output R 01 – True Output
148 – Ground Start R 01 – True Output
149 – Alternate Communicator
R 01 – True Output
R 02 – Timed Output
o 04 – Fire Alarm
o 05 – Panic Alarm
o 06 – Burglary Alarm
o 07 – Open/Close
o 08 – Zone Auto Bypass
o 09 – Medical Alarm
o 10 – Burglary Verified
o 11 – Open After Alarm
o 12 – Emergency Alarm
o 13 – Duress Alarm
o 14 – Holdup Verified
155 – System Trouble
R 01 – True Output
o 02 – Timed Output
R 04 – Service Required
R 05 – Loss of Clock
R 06 – DCTrouble
R 07 – Bus Voltage
R 08 – ACTrouble
R 09 – Device Fault
R 10 – Device Battery
R 11 – Device Tamper
R 12 – RFDelinquency
R 13 – Module Supervisory
R 14 – Module Tamper
R 15 – Communications
R 16 – Not Networked
- 135 -

DSC HS2016 Specifications

General

Mounting Type	Wall mount
Power Supply	16.5VAC
Battery Backup	12VDC
Operating Temperature	32°F to 120°F (0°C to 49°C)
Dimensions	267mm
