DSC HS2016 Reference Manual

Section 6: Programming Worksheets
[010] [000 - 164] PGM Attributes
156 – Latched System Event
R 01 – True Output
o 02 – Timed Output
R 04 – Fire Alarm
R 05 – Panic Alarm
R 06 – Burglary Alarm
R 07 – Medical Alarm
R 08 – Supervisory
R 09 – Priority Event
R 10 – Holdup
R 11 – Duress Alarm
R 12 – Emergency Alarm
R 13 – Fire Supervisory
R 14 – Fire Trouble
R 15 – CO Alarm
157 – System Tamper
R 01 – True Output
o 02 – Timed Output
R 09 – Module Tamper
R 10 – Zone Tampers
161 – DC Trouble
R 01 – True Output
o 02 – Timed Output
R 09 – Battery Low
R 10 – Battery Absent
165 – Prox Used R 01 – True Output
166 – Prox Used Part
R 01 – True Output
o 02 – Timed Output
175 – Bell Prog Access R 01 – True Output
176 – Remote Operation
R 01 – True Output
o 02 – Timed Output
- 136 -

DSC HS2016 Specifications

General

Mounting Type	Wall mount
Power Supply	16.5VAC
Battery Backup	12VDC
Operating Temperature	32°F to 120°F (0°C to 49°C)
Dimensions	267mm
