DSC HS2016 Reference Manual

Section 6: Programming Worksheets
[311] Partition 1 Call Directions
Description on page 1
001 – Partition 1 Alarm/ Restore:
R Receiver #1 o Receiver #3
o Receiver #2 o Receiver #4
002 – Partition 1 Tamper/ Restore:
R Receiver #1 o Receiver #3
o Receiver #2 o Receiver #4
003 – Partition 1 Opening/ Closing:
oReceiver #1 o Receiver #3
o Receiver #2 o Receiver #4
[312]
Partition 2 Call Directions
001 – Partition 2 Alarm/ Restore:
R Receiver #1 o Receiver #3
o Receiver #2 o Receiver #4
002 – Partition 2 Tamper/ Restore:
R Receiver #1 o Receiver #3
o Receiver #2 o Receiver #4
003 – Partition 2 Opening/ Closing:
o Receiver #1 o Receiver #3
o Receiver #2 o Receiver #4
[313]
Partition 3 Call Directions
001 – Partition 3 Alarm/ Restore:
R Receiver #1 o Receiver #3
o Receiver #2 o Receiver #4
002 – Partition 3 Tamper/ Restore:
R Receiver #1 o Receiver #3
o Receiver #2 o Receiver #4
003 – Partition 3 Opening/ Closing:
o Receiver #1 o Receiver #3
o Receiver #2 o Receiver #4
[314]
Partition 4 Call Directions
001 – Partition 4 Alarm/ Restore:
R Receiver #1 o Receiver #3
o Receiver #2 o Receiver #4
002 – Partition 4 Tamper/ Restore:
R Receiver #1 o Receiver #3
o Receiver #2 o Receiver #4
003 – Partition 4 Opening/ Closing:
o Receiver #1 o Receiver #3
o Receiver #2 o Receiver #4
[315]
Partition 5 Call Directions
001 – Partition 5 Alarm/ Restore:
R Receiver #1 o Receiver #3
o Receiver #2 o Receiver #4
002 – Partition 5 Tamper/ Restore:
R Receiver #1 o Receiver #3
o Receiver #2 o Receiver #4
003 – Partition 5 Opening/ Closing:
o Receiver #1 o Receiver #3
o Receiver #2 o Receiver #4
[316]
Partition 6 Call Directions
001 – Partition 6 Alarm/ Restore:
R Receiver #1 o Receiver #3
o Receiver #2 o Receiver #4
002 – Partition 6 Tamper/ Restore:
R Receiver #1 o Receiver #3
o Receiver #2 o Receiver #4
- 160 -
