Section 7: Troubleshooting
Trouble [05] Device Faults Press [05] to determine specific trouble
Trouble Troubleshooting
[01] Zone 1-128 faults
Wireless zones:
Enter [01] to view zones in fault. This trouble is
generated by a zone wireless supervisory trouble.
Ensure fire zones have a 5.6K resistor (green, blue, red) connected.
Remove wire leads from Z and COM terminals and measure resistance of the wire
leads:
Check for a short on DEOL zones or an open condition on SEOL fire zones.
Connect a 5.6K resistor across the Z and COM terminals. Verify the trouble condition
clears.
Placement test a wireless device and re-locate it if bad results are received.
Hardwired zones:
Enter [01] to view zones in fault.
“Fire Zone” is displayed in the [*][2] menu if an open
circuit is present on PGM2 being used as a 2-wire smoke
detector input.
This trouble is generated by a short on hardwired zones
when DEOL is used.
Ensure a 2.2K EOL resistor is connected (red, red, red).
Remove wire leads from PGM2 and AUX+ terminals and measure resistance of the
wire leads:
An open circuit indicates a break in the wiring or no resistor connected.
Connect a 2.2K resistor across PGM2 and AUX+ terminals. Verify that trouble clears.
[02] Keypad 1-16 faults
Enter [02] to view keypads in fault. This trouble is caused
by a wireless supervisory fault if the keypad is wireless.
Placement test the wireless keypad and re-locate if needed.
[03] Siren 1-16 faults
This trouble is caused by a wireless supervisory fault on a
wireless siren.
See [02] Keypad 1-16 faults above.
[04] Repeater 1-8 faults
This trouble is caused by a wireless supervisory fault on a
wireless repeater, or by the repeater shutting down due
to a loss of AC/DC power.
See [02] Keypad 1-16 faults above.
Additional trouble conditions:
Fire (2-W Smoke, PGX916, PGX926)
Freeze (PGX905)
Self Test (PGX984)
CO (PGX913)
Probe Disconnected (PGX905)
- 184 -
