DSC HS2016

Section 3: Configuration
Module HS2016-
4
HS2016 HS2032 HS2064/
HS2064 E
HS2128/HS2128 E
Wireless Keypad:
HS2LCDRF(P)4
HS2ICNRF(P)4
HS2LCDWF(P)(V)4
8
8 8 8 16
HS2TCHP Touchscreen Keypad
8
8 8 8 16
HSM2300 Power Supply 1A
3
3 3 3 4
HSM2204 4 High-current Output
1
1 1 3 4
HSM2HOSTx Transceiver
1
1 1 1 1
HSM2955
(not UL evaluated)
1
1 1 1 1
Modules can be enrolled automatically or manually using section [902] of Installer programming. For instructions on
enrolling modules, see "Module Programming" on page 118.
To confirm that a module has been successfully enrolled, use Installer Programming section [903]. See "[903] Confirm Mod-
ule" on page 119 for details.
Enrolling the First Keypad
To enroll a hardwired keypad, connect the keypad to the alarm controller, power up the alarm panel then press any button
on the keypad.
To enroll a wireless keypad, first connect the HSM2HOSTx wireless integration module to the alarm controller. Next, power
up the alarm panel and a wireless keypad. Press any button on the keypad to enroll it on the HSM2HOSTx. The
HSM2HOSTx is then enrolled on the alarm panel. To enroll other keypads, see "Module Programming" on page 118.
3.3.2 Module Supervision
By default, all modules are supervised upon installation. Supervision is enabled at all times so that the panel can indicate a
trouble if a module is removed from the system.
To check which modules are currently connected and supervised, see "[903] Confirm Module" on page 119.
If a module is connected but is not recognized by the system, it may be due to any of the following reasons:
l the module is incorrectly wired to the alarm controller
l the module has exceeded its maximum wire run length
l the module does not have enough power
l the module is not enrolled on the wireless receiver
Removing Modules
Enrolled modules can be deleted from the system via programming section [902]. For instructions, see "[902] Add/Remove
Modules" on page 118.
3.3.3 Enroll Wireless Devices
Wireless devices are enrolled via the wireless transceiver module and Installer Programming section [804][000]. See "Com-
patible Devices" on page 8 for a list of supported wireless devices.
Wireless devices are enrolled using one of the following methods:
Auto Enrollment
To enroll a wireless device using this method, press and hold the Enroll button on the device for 2-5 seconds until the LED
lights then release the button. The alarm panel automatically recognizes the device and the keypad displays a confirmation
- 29 -
