Section 5: Programming
Timed Output Latching Follow Alarm PGM Output
OFF OFF OFF
ON upon zone opening (including tamper and fault), OFF upon zone closing
OFF OFF ON
ON upon zone alarm, OFF upon bell cut-off or alarm silenced
OFF ON OFF
ON upon zone opening, OFF upon valid code
OFF ON ON
ON upon zone alarm, OFF upon valid code
ON OFF OFF
ON upon zone opening, OFF upon PGM timer expires
ON OFF ON
ON upon zone alarm, OFF upon PGM timer expires
ON ON OFF
ON upon zone opening, OFF upon valid code
ON ON ON
ON upon zone alarm, OFF upon valid code
201 – 216 Zone Follower Zones 1-128
01 – True Output/Inverted
ON: deactivated during normal operation. Activated when triggered.
OFF: activated during normal operation. Deactivated when triggered.
02 – Timed Output
ON: output remains active until the PGM output timer expires.
OFF: output remains active until an access code has been entered.
09-16 – Zone Terminals 1-8
ON: zones associated with terminals 1-8 are enabled for zone follower operation.
OFF: zones are not enabled for zone follower operation.
5.3.8 [011] PGM Configuration Options
This section is used to configure PGM types that offer multiple options.
[001]-[164] Select PGM
The following options may be selected for each PGM:
Zone Follow PGM By Zone
This option is used to specify the zone that PGM type 200 follows. Enter 001-128 to select zone 1-128.
Proximity Tag Used
This option is used to define which proximity tag will activate PGM outputs programmed as [165] Prox Used. Enter 000 to
enable this PGM attribute for all user proximity tags, or enter user number 0002-1000 to have this attribute activated by a spe-
cific user proximity tag.
Command Output 1-4
This option is used to assign a schedule, programmed in section [601]-[604], for the command output PGMs to follow. Pro-
gram 001-004 to for schedules 1-4. Program 000 to activate the PGM when a proximity tag is presented.
5.3.9 [012] System Lockout
Keypad Lockout – Number of Invalid Local Attempts
This option controls the number of invalid access code entries allowed before the keypad is locked.
When keypad lockout occurs, the system is inaccessible by keypad for the programmed duration. If the number of invalid
attempts is not reached within one hour, or if a valid access code is entered, the counter is reset to 0. Valid entries are 000 to
255 minutes. Entering 000 disables the feature. Presenting an invalid tag counts toward keypad lockout.
Note: For EN 50131 certified installations, maximum number of attempts is 10.
- 85 -
