Push To Set Zone Type (32)*
When a partition to which this zone is assigned is armed,
the exit delay for that partition will proceed normally until
the end of the exit delay is reached. At that time the exit
delay will continue to be annunciated but the partition
will not arm. To arm the partition the Push To Set Zone
must be violated and restored. Upon momentary violation
of this zone, any exit delay active for the partitions to
which the zone is assigned will be terminated.
NOTE: This zone type should not be programmed as
global.
Function Key Zone (33)
The Function Key Zone definition, when selected, causes
the panel to prompt the function key list and allow the
installer to select the following list of functions:
When this zone is violated the panel will perform the
appropriate function for the partition to which the zone is
assigned. No access code is required. Tampers, Faults, or
Device Faults on the zone will not cause the panel to per-
form the respective function (even if Tamper/Fault Opens
Zone is enabled). The installer should ensure that the
method provided to activate this zone provides sufficient
security for the function being performed.
NOTE: The zone attributes of this zone type should
never be used. This zone type should not be pro-
grammed as global.
Zone Attributes
The following is a description of each zone option. Scroll
through each option and press [*] to toggle between on
and off. When all necessary changes are made, press [#] to
return to the previous menu.
Each zone type has different attributes enabled by default.
For a list of these default settings, see the Programming
Worksheets.
• Bell Audible – This will determine whether the zone
will activate bell outputs and PGM outputs pro-
grammed to sound fire/burglary alarms when an
alarm occurs. Select [Y] for audible, [N] for silent.
• Bell Pulsed – This will determine how the bell outputs
and PGM outputs programmed to sound fire/burglary
alarms will sound for an alarm. Select [Y] for pulsed,
[N] for steady.
• Bypass Enable – This will allow the zone to be manu-
ally bypassed. Select [Y] to allow bypassing by the
user, [N] to prevent it. This attribute should not be
enabled for Fire zones.
• Chime Function – If the door chime option is enabled,
keypad will chime both when the zone is violated and
restored. Select [Y] for chime, [N] for no chime. To acti-
vate/deactivate the Door Chime feature for a partition,
enter [*][4] at a keypad.
• Force Arm – When force arming is enabled, the parti-
tion(s) the zone is assigned to can be armed even if the
zone is not secure. The zone will be temporarily
bypassed and will be added back into the system if it is
later restored. Select [Y] to enable this feature. If [N] is
selected, the zone must be secured or manually
bypassed before arming will be allowed.
• Swgr Shut Down – Swinger shutdown. After the zone
has reported the programmed number of alarms, the
zone will be shut down. Swinger shutdown is reset
every time the panel is armed, or when the clock
reaches midnight. See 10.5 ‘Swinger Shutdown‘.
Select [Y] to enable this feature. If [N] is selected, the
panel will always transmit when an alarm occurs.
• TX Delay – Transmission delay. When the zone goes
into alarm, the panel will sound the bell outputs
immediately but will delay communication to the cen-
tral station for the programmed amount of time. If the
zone is disarmed before this time expires, no transmis-
sion is sent. If not, the panel will transmit the alarm
after the delay expires.
Select [Y] to enable this feature. If [N] is selected, the
panel will communicate immediately. To program the
Transmission Delay, see 10.9 ‘Transmission Delay‘
• Waterflow Del – This will enable the waterflow delay
for waterflow zones. Waterflow delay operates similar
to transmission delay except both the fire output and
communications will be delayed. If the zone is restored
before the programmable delay time, no transmission
is sent.
Select [Y] to enable this feature. If [N] is selected, the
panel will immediately activate the fire output and
communicate to central station.
• Non-Latch Toggle - Waterflow and Supervisory Zones
When the panel is used for pure supervisory/water-
flow reporting - no alarm bells – the waterflow and
supervisory zone type is non-latching. When the panel
is used as a local fire panel and sounds local fire alarm
horns for evacuation, these zones types must be latch-
ing.
The following two options address these requirements:
Waterflow Latch, Fire Sup Latch.
Zone 1 Fast Loop Response
If the option Zone 1 Fast (ref # [000200]) is enabled, Zone 1
will have a loop response time of 32ms. If the option is dis-
abled, Zone 1 will have a normal loop response time
(512ms). The option is disabled by default.
* Do not use in UL Listed installation.
** Use only in conjunction with a device UL Listed for fire.
(00) Null Key
(01) Stay Arm
(02) Away Arm
(03) No-entry Arm
(04) Chime On/Off
(05) System Test
(06) Quick Exit
(07) Arm Interior
(08) Command O/P 1
(09) Command O/P 2
(10) Command O/P 3
(11) Command O/P 4
(12) Command O/P 5
(13) Command O/P 6
(14) Command O/P 7
(15) Command O/P 8
(16) Silence Trouble
(17) Silence Bells
(18) Fire Reset**
(19) Fire Drill
(20) Lamp Test
(21) Fire Insp Tst
(22) Quick Bypass
(23) Music Input
(24) Maid’s Code
(25) Cancel Key
