DSC MAXSYS PC4020 Installation Manual

51
Appendix B: Zone Reporting Codes
For notes on Contact ID and SIA reporting codes, see Appendix A.
* If Contact ID is used, the above reporting codes are suggested. ** ZZZ = zones 001-128
Zone Definition Contact ID Auto Rep Codes* SIA Auto Rep Codes**
Zone
Alm/Rest.
Zone
Troub/Tam
Alm/Rest.
Zone
Fault/Rest.
Zone Alm/Rest. Zone
Troub/Tam
Alm/Rest.
Zone
Fault/Rest.
Standard Delay, Auxiliary Delay,
Instant, Interior, Interior Delay,
Interior Stay/Away, Delay
Stay/Away
(1) 3A (3) 83 (3) 8A BA-ZZZ/BH-ZZZ TA-ZZZ/TR-ZZZ UT-ZZZ/UJ-ZZZ
Standard Fire, Delayed Fire, Auto
Verify Fire
(1) 1A (3) 73 (3) 73 FA-ZZZ/FR-ZZZ FT-ZZZ/FJ-ZZZ FT-ZZZ/FJ-ZZZ
Waterflow (1) 13 (3) 73 (3) 73 SA-ZZZ/SH-ZZZ ST-ZZZ/SJ-ZZZ ST-ZZZ/SJ-ZZZ
Fire Supervisory (2) AA (3) 73 (3) 73 FS-ZZZ/FR-ZZZ FT-ZZZ/FJ-ZZZ FT-ZZZ/FJ-ZZZ
LINKS Supervisory (3) 8A (3) 8A (3) 8A US-ZZZ/UR-ZZZ US-ZZZ/UR-ZZZ US-ZZZ/UR-ZZZ
24Hr Bell, 24Hr Bell/Buzzer, 24Hr
Buzzer
(1) 3A (3) 83 (3) 8A BA-ZZZ/BH-ZZZ TA-ZZZ/TR-ZZZ UT-ZZZ/UJ-ZZZ
24Hr Technical (1) 5A (3) 83 (3) 8A UA-ZZZ/UH-ZZZ TA-ZZZ/TR-ZZZ UT-ZZZ/UJ-ZZZ
24Hr Gas (1) 5A (3) 83 (3) 8A GA-ZZZ/GH-ZZZ TA-ZZZ/TR-ZZZ UT-ZZZ/UJ-ZZZ
24Hr Heat (1) 5A (3) 83 (3) 8A KA-ZZZ/KH-ZZZ TA-ZZZ/TR-ZZZ UT-ZZZ/UJ-ZZZ
24Hr Medical (1) AA (3) 83 (3) 8A MA-ZZZ/MH-ZZZ TA-ZZZ/TR-ZZZ UT-ZZZ/UJ-ZZZ
24Hr Emergency (1) A1 (3) 83 (3) 8A QA-ZZZ/QH-ZZZ TA-ZZZ/TR-ZZZ UT-ZZZ/UJ-ZZZ
24Hr Water (1) 5A (3) 83 (3) 8A WA-ZZZ/WH-ZZZ TA-ZZZ/TR-ZZZ UT-ZZZ/UJ-ZZZ
24Hr Freeze (1) 5A (3) 83 (3) 8A ZA-ZZZ/ZH-ZZZ TA-ZZZ/TR-ZZZ UT-ZZZ/UJ-ZZZ
24Hr Holdup (1) 22 (3) 83 (3) 8A HA-ZZZ/HH-ZZZ TA-ZZZ/TR-ZZZ UT-ZZZ/UJ-ZZZ
24Hr Panic (1) 2A (3) 83 (3) 8A PA-ZZZ/PH-ZZZ TA-ZZZ/TR-ZZZ UT-ZZZ/UJ-ZZZ
Latching 24Hr (1) 3A (3) 83 (3) 8A BA-ZZZ/BH-ZZZ TA-ZZZ/TR-ZZZ UT-ZZZ/UJ-ZZZ
Momentary Arm, Maintained Arm n/a n/a n/a n/a n/a n/a
Forced Answer n/a n/a n/a n/a n/a n/a
LINKS Answer n/a n/a n/a n/a n/a n/a
AC Delay n/a n/a n/a n/a n/a n/a
Suggested Contact ID Event Codes: The numbers in brackets are not programmable. The two-digit number following the brackets is
the programmable reporting code.
Medical Alarms
(1)AA Medical
(1)A1 Pendant Transmitter
(1)A2 Fail to Report In
Fire Alarms
(1)1A Fire Alarm
(1)11 Smoke
(1)12 Combustion
(1)13 Water Flow
(1)14 Heat
(1)15 Pull Station
(1)16 Duct
(1)17 Flame
(1)18 Near Alarm
Panic Alarms
(1)2A Panic
(1)21 Duress
(1)22 Silent
(1)23 Audible
Burglar Alarms
(1)3A Burglary
(1)31 Perimeter
(1)32 Interior
(1)33 24 Hour
(1)34 Entry / Exit
(1)35 Day / Night
(1)36 Outdoor
(1)37 Tamper
(1)38 Near Alarm
General Alarms
(1)4A General Alarm
(1)43 Exp. module failure
(1)44 Sensor tamper
(1)45 Module Tamper
24 Hour Non-Burglary
(1)5A 24 Hour non-Burg
(1)51 Gas detected
(1)52 Refrigeration
(1)53 Loss of Heat
(1)54 Water Leakage
(1)55 Foil Break
(1)56 Day Trouble
(1)57 Low bottled Gas level
(1)58 High Temp
(1)59 Low Temp
(1)61 Loss of Air Flow
