Section 1: Introduction
1.1 Out Of The Box
Please verify that the following components are included
in the PC4020 package.
❑ 1 PC4050C or PC4001C cabinet
❑ 1 Version 3.3 main control module
❑ 1 Hardware package which includes:
❑ 32 EOL resistors (5600Ω)
❑ 1 Black cabinet plug
❑ 1 Green ground strap
❑ PCB mounting standoffs
❑ 1 set of documents which includes:
❑ 1 Installation Manual
❑ 1 Programming Worksheets
❑ 1 Instruction Manual
1.2 Specifications and Features
Main Control Panel
• AC Input – 16 V
AC, 40VA minimum
• Battery Charger – 350 mA to charge 12V
DC lead-acid
batteries
• Bell Circuit – 12 VDC, 700 mA continuous maximum
• Auxiliary Power Output: 12 V
DC, 500 mA maximum
• Switched Auxiliary Power Output 12 V
DC, 300 mA
maximum
• PGM 1 & 2 – two options:
•12 V
DC, 50 mA maximum each as standard outputs
•12 VDC, 170 mA maximum each when used for
addressable loop
• 4-wire Combus power – 500 mA maximum
• 16 Zone inputs
• Supervised dialer output
• Earth ground connection
• All outputs rated to operate over the range of 11.6 to
12.6V for UL Listed systems.
Expansion Capabilities
• Up to 128 zones total using
• PC4108A 8-zone input modules
• PC4116 16-zone input modules
• PC4164 v2.x wireless receivers and wireless devices
• PGM outputs for addressable devices
• Up to 16 keypads total using
• LCD4501 keypad (with function keys) - v2.0 or later
• LCD4500 keypad - v2.02 for function key support
(number keys 1-5)
• Up to 144 low power outputs total using
• PC4216 low power output modules (v2.1 required
for Temporal Fire option)
• Up to 64 relay outputs total using
• PC4204 quad relay and power supply module; also
for Combus repower (v2.1 required for Temporal
Fire option)
• PC4204CX Combus repeater
• Up to 8 supervised bell outputs total using
• PC4702BP (up to 4)
• Up to 32 card access-controlled doors
• PC4820 dual card reader modules (up to 16)
• System Printer/DVACS* output using
• DataLink**
• PC440X module
• Dual phone line and Class ‘B’ fire zones using
• PC4701 fire module
• Backup communication using
• LINKS1000 cellular communicator
• LINKS2150 long-range transmitter
• LINKS2450 long-range transmitter**
• Any compatible alternate communication module**
• T-Link TCP/IP Ethernet Communicator (see the
T-Link Installation Manual part no. 29001007)
• Skyroute Max
• Telephone access & automation items using
• ESCORT4580 Audio Assistant (v1.3 or greater)
• Remote annunciation using
• PC4612 – 12-zone point annunciator
• PC4632 – 32-zone point/graphic annunciator
• PC4664 – 64-zone point/graphic annunciator
• Central station talk/listen** and intercom capabilities
using:
• PC4936 audio interface module
• PC4937 8-port expansion module
• LCD4501/4500 keypad and audio station
• PC5921 audio stations
• Up to 32 telephone entry doors
• PC4850 module (up to 16)**
Downloading Capabilities
• Downloading Software: DLS-3 v1.3**
• PC-Link connector – for local upload/download
• End user PC-Link using PC4401 as isolator**
• DataLink access using PC4401
• T-Link TCP/IP module
* DVACS is a registered trademark of Electro Arts Limited
** Not UL Listed. Do not use in conjunction with UL Listed systems.
